AC-DC Module fais fab mov
01
FAQ20-05D0512-WFCI fais fab mov
cov khoom piav qhia
1. Cov zis voltage raug ± 2%;
2. 4000V siab cais voltage;
3. -40 ~ + 60 ℃ ua haujlwm kub;
4. Rwb thaiv tsev tsis kam ≥100MΩ;
5. Kev ua haujlwm zoo li ntawm 70% mus rau 80%.
6. Kev tiv thaiv luv luv, tiv thaiv overheat;
Kev ua tau zoo
● Plaub txoj kev tso zis hom
● Tag nrho cov zis hluav taws xob 20W
● Cov zis voltage Vo1: 5V;Vo2:5V;Vo3:5V;Vo4:12V
● Input voltage ntau 85 ~ 265VAC
● Kev rho tawm voltage 2500VAC
● Zuag qhia tag nrho qhov ntev 69.5 * 47.5 * 23.5
Input yam ntxwv
| Input Voltage Ntau (DC) | 85 ~ 265VAC |
Output yam ntxwv
| Output voltage raug | Vo1 nominal tso zis voltage ± 2%; Voltage 2, Vo3, Vo4 Nominal tso zis voltage ± 5% |
| Load effect | 0% ~ 100% load, ≤ ± 0.5% |
| Tau qhov twg los | Rated load, ≤ ± 0.2% |
| Ripple suab nrov | ≤ 1% Qhov siab (max) |
| Conversion efficiency | Nominal input, ntsuas loadtyp.80% |
| Kub coefficient | ≤ ± 0.02% / ℃ |
General yam ntxwv
| Kev rho tawm voltage | Vin ~ Vout, Vin ~ FG, Vout ~ FG Tag nrho peb yog 2500VAC / min |
| Rwb thaiv tsev tsis kam | ≥100MΩ |
| Lub sijhawm nruab nrab ntawm kev ua tsis tiav | ≥1 × 106h |
| Kev tiv thaiv muaj nuj nqi | Kev tiv thaiv luv luv (kev rov qab los ntawm tus kheej), kev tiv thaiv overcurrent (tus kheej rov qab) |
| Ua haujlwm kub | −25 ~ + 55 ℃ Puv load service / + 55 ~ + 85 ℃ Derated siv |
| Cia kub | -40 ~ + 105 ℃ |
| Cia cov av noo | ≤ 95% RH |
| Txias hom | Ntuj cua txias |
Cov duab kos duab
Pin txhais
| Txhais | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| Cov lus qhia | FG | N | L | -Vo 1 | +Vo 1 | Vo 2 | Nrog | Vo 3 | -Vo 4 | +Vo 4 |
